3m (9.8′) range EchoPod® DL24 Multi-Function Ultrasonic Liquid Level Sensor Transmitter

SPECIFICATIONS Range: 9.8’ (3m) Accuracy: ± 0.2% of range Resolution: 0.039” (1mm) Dead band: 4” (10cm) Beam width: 2” (5.08cm) Configuration: WebCal™ PC, Windows®, USB 2.0 Memory: Non-volatile Supply voltage: 24 VDC (loop) Consumption: 0.5W Loop resist.: 400Ω max Signal output: 4-20 mA, two-wire Signal invert: 4-20 mA or 20-4mA Signal fail-safe: 4 mA, 20 mA, 21 mA, 22 mA or hold last Contact type: (4) SPST relays Contact rating: 60 VA, 1A maximum Contact fail-safe: Power loss: Hold last, Echo loss: Open, close or hold last Hysteresis: Selectable Process temp.: F: 20° to 140°, C: -7° to 60° Temp. comp.: Automatic Ambient temp.: F: -31° to 140°, C: -35° to 60° Pressure: MWP = 30 PSI (2 bar) Enclosure rating: Type 6P, encapsulated, corrosion resistant & submersible Encl. material: Polycarbonate Trans. material: PVDF Cable jacket mat: Polyurethane Cable type: 9-conductor, shielded Cable length: 48” (1.2m) Process mount: 1” NPT (1” G) Mount gasket: Viton® Classification: General purpose Compliance: CE, RoHS Approvals: cFMus
